NovaStar TB30
NovaStar TB30
The TB30 is NovaStar's best-selling multimedia player, combining powerful performance with exceptional reliability for commercial LED displays. With 650,000 pixel capacity, 2x Gigabit Ethernet outputs with primary/backup support, and 4K@60Hz hardware video decoding, it delivers professional-grade performance. Running Android 11, the TB30 integrates playback and sending card capabilities, enabling remote content publishing and screen control via computer, mobile phone, or tablet. Cloud-based publishing and monitoring platforms allow users to manage LED displays from any Internet-connected device anywhere, anytime. Thanks to its reliability, ease of use, and intelligent control, the TB30 is the winning choice for commercial LED displays and smart city applications including fixed displays, lamp-post displays, chain store displays, advertisement players, retail store displays, door head displays, shelf displays, and more. Features include USB 3.0 support, dual Wi-Fi modes, sensor connectors for brightness/temperature monitoring, and comprehensive security measures.
Key Highlights
Key Features
Backup
Technical Specifications
Video Processing
| layers | 1 layer |
| Maximum Pixels | 650K pixels |
| Maximum Width | 4096 pixels |
| Maximum Height | 4096 pixels |
Input Connectors
| INPUTS | • 1x USB 3.0 (Type A) port • 1x USB (Type B) port |
Output Connectivity
| Ethernet Output | 2x Gigabit Ethernet |
| Ethernet Control | 1x Gigabit Ethernet (network/control) |
| Audio Output | 1x Stereo audio output (OMTP headphones, 48kHz sample rate) |
| Wi-Fi | 2.4 GHz Wi-Fi (AP and Sta modes simultaneously) |
| USB Ports | 1x USB 3.0 Type-A (upgrade/play/storage expansion, supports Ext4 and FAT32), 1x USB Type-B (for controlling computer connection) |
| Sensor Connectors | 2x Sensor connectors (brightness sensor or temperature and humidity sensor) |
Hardware
| Processor | Quad-core ARM A55 processor @1.8 GHz |
| RAM | 1 GB |
| Storage | 32 GB |
| Operating System | Android 11 |
| Video Decoding | Hardware decoding of H.264/H.265 4K@60Hz videos |
| Playback Capability | 1x 4K, 2x 1080p, 4x 720p, 4x 480p, or 6x 360p videos |
Physical Specifications
| Power Input | 100-240V~, 50/60Hz, 0.6A |
| Dimensions | 274.3 mm × 139.0 mm × 40.0 mm (10.8" × 5.5" × 1.6") |
| Net weight | 1228.9 g (2.7 lbs) |
| IP Rating | IP20 |
Features
Working Modes
| • Synchronous |
| • Asynchronous |
Software
| Firmware 4.7.7.1501 | ⬇️ Download |
| NovaLCT 5.8.0 | ⬇️ Windows |
| ViPlex Express 3.0.5.1501 | ⬇️ Windows |
| Compatible Software | NovaLCT, ViPlex Express |
Why Choose the TB30?
✓ All-in-One Design
Integrated solution saves rack space and simplifies setup
✓ Professional Features
Advanced processing with low latency and pixel-level calibration
✓ Maximum Reliability
Backed by 3-Year NovaStar Warranty plus Olympian LED support
✓ Proven Performance
Trusted by production companies and rental houses nationwide
Frequently Asked Questions
Q: What is the default Wi-Fi password?
For older Taurus devices, the default Wi-Fi password is "12345678". For newer devices, the default password is "SN2008@+" unless you have already changed it. If you are locked out, there is a factory reset button on the device that will restore the default password, but this will also cause it to lose all configurations.
Q: How do I configure the TB30 with NovaLCT?
Taurus media players are configured slightly differently from regular controllers. In NovaLCT go to User -> Media Player Login, select the device from the list and click "Connect System". The username is admin and the password will be 123456 or SN2008@+
Q: How do I update the Firmware on TB30?
In ViPlex Express go to Control -> Player Upgrade. Click on "..." and specify the path to the .nuzip file. If you only have the .zip version you need to extract it so you can use the .nuzip file.
Q: What warranty is included?
All NovaStar products include a full 3-year manufacturer warranty when purchased from authorized distributors like Olympian LED.
Q: Do you offer volume pricing?
Yes! As the largest NovaStar distributor in the USA, we offer special pricing for bulk orders and repeat customers. Contact our sales team for a custom quote.
Q: Do you have this in stock?
We maintain over $2 million in inventory at our Titusville, Florida warehouse. Most orders ship same-day. Contact us to confirm current availability.
Q: Can I get NET 30 payment terms?
NET 30 terms are available for qualified businesses and established customers. Please contact our sales team to discuss payment options.
